4" ZDS O3 FDA Approved Oil immersed single phase submersible motor.
Standard 4" NEMA coupling.
Comes with 1.5m Cable w/ connector.
Requires Control Box w/ 40uF Capacitor.
- kW: 1,1
- Voltage range: 220-230V / 50Hz
- Flange: 4" NEMA standard dimensions
- Voltage tolerance 50Hz from nominal: +6% / -10% Un
- Rotation: ccw, facing shaft end
- Degree of protection: IP 68
- Insulation: F
- Rated ambient temperature: max 40° C
- Cooling flow: min 8 cm/sec
- Maximum starts/h: 150, equally distributed
- Mounting: vertical/horizontal, shaft upwards
- Maximum immersion depth: 150 m
- Allowed range of water pH: 6,4 - 8,0
- Thrust: 2.500N
- Protection requirements: For O3 motors without the control box CBO an overload protection and a control unit for motor start and run must be installed according to EN 60947-4-1 trip time < 10 sec. at 5xIn.
